YZ6F Direct ophthalmoscope (Halogen lamp)
?
Sign In
CE Certified
Elevate your clinical examinations with the YZ24B + YZ11D Double Charge Retinoscope with Ophthalmoscope. Designed for ophthalmologists, optometrists, and eye care professionals, this dual-purpose diagnostic set delivers exceptional optical performance, reliable rechargeable power, and portable convenience — whether you're in a clinic, hospital, or on mobile outreach.
| Working Distance | 0.67m |
| Streak | 3mm–20mm |
| Illumination Source | 3.5V/2.8W halogen bulb |
| Streak Rotation | 360° |
| Input Voltage | AC220V ±22V / 50Hz±1Hz, AC110V ±11V / 60Hz±1Hz |
| Power (Main Body of Ophthalmoscope) | Li+ battery pack DC:3.7V |
This portable ophthalmoscope features an improved optical design that delivers excellent optical performance in a compact, travel-friendly form factor. Ideal for mobile inspections, bedside exams, and field use.
| Illumination Form | Large Spot, Small Spot, Slit, Net, Red Free |
| Diopter Compensation | 0 ±1 ±2 ±3 ±4 ±5 ±6 ±8 ±10 ±12 ±16 ±20 -25 -35D |
| Illumination Source | 3.5V/2.8W, Halogen Bulb |
| Input Voltage | AC220V ±22V / 50Hz±1Hz, AC110V ±11V / 60Hz±1Hz |
| Power (Main Body of Ophthalmoscope) | Li+ Battery Pack 3.7V, Rechargeable |
| Size: | 30 x 31 x 14(cm) |
| Gross Weight: | 2.7kgs |
