YZ24B+YZ11D Retinoscope with ophthalmoscope rechargable (halogen lamp)

Item# YZ24B-YZ11D

Abstract Rechargable seat with 2 head, one retinoscope head, another one is ophthalmoscepe head, click to see details......

Get Quote

Add to Quote

Description

Packaging Detail

Unit: ctns,cm,kg,m³,pcs

Desc.	Length	Width	Height	NW.	GW.	CBM	CBM/5000	CBM/6000
1pcs	30	25	15	2	3	0.011	2.2	1.833
Total				2	3	0.011	2.2	1.833

CE Certified

Two instrument heads with one handle — a smart, money-saving solution for eye care professionals.

YZ24B
Key Features:
■ Filament rotates 360° and moves up and down for precise alignment.
■ Quickly and accurately measures the astigmatism axis.
■ Light can be converged, radiated, or paralleled to suit different examination needs.
■ Continuously adjustable brightness for optimal patient comfort.
■ Convenient quick recharging saves time between patients.
■ Anti-recharging and anti-discharging function protects the battery and extends its lifespan.
■ Can also be connected with the ophthalmoscope head for added versatility.

Specifications:
Working Distance	0.67m
Streak	3mm–20mm
Illumination Source	3.5V/2.8W halogen bulb
Streak Rotation	360°
Input Voltage	AC220V ±22V/ 50Hz±1Hz、AC110V ±11V/ 60Hz±1Hz
Power (Main Body of Ophthalmoscope)	Li+ battery pack DC:3.7V

YZ11D
Product Overview:
This portable device delivers excellent optical performance thanks to an improved optical design.
Key Features:
■ Improved light path for excellent optical performance.
■ Imported halogen bulb provides high, adjustable brightness and excellent color rendering.
■ Smart, portable, and convenient for mobile inspection.
■ Equipped with a special charger for quick, convenient recharging and protection against overcharging.
■ Anti-recharging and anti-discharging function protects the battery.

Specifications:
Illumination Form	Large Spot, Small Spot, Slit, Net, Red Free
Diopter Compensation	0 ±1 ±2 ±3 ±4 ±5 ±6 ±8 ±10 ±12 ±16 ±20 -25 -35D
Illumination Source	3.5V/2.8W, Halogen Bulb
Input Voltage	AC220V ±22V/ 50Hz±1Hz、AC110V ±11V/ 60Hz±1Hz
Power (Main body of Ophthalmoscope)	Li+ Battery Pack 3.7V, Rechargeable
