LE-300 Auto lens edger (glass, resion, CR lens, flat polishing)
Price
$
Login
Item#
LE-300
Abstract
Common lens,flat polishing.
已选清单
0种
0件
Description
CE
Features:
Auto-Clip System:
Use of third gear pressure on the lens without damage.
Automatic emendation procedure:
Automatic emendation of the lens size, initial zero Proofreading during the start of grinding, obvious improvement of precision.
Wheel Configuration:
Standard configuration of four wheels (Resin coarse grinding wheel/ Glass coarse grinding wheel, V-flat edge / sharp edges fine grinding wheel, flat edge polished wheels )
Click below link to check the difference for LE series Lens Edgers
https://www.jhoptical.cn/articles/LE-lens-edger-differences.html
Specification: | |
Technical parameter: | Min22mm Max100mm |
Range of adjustable measurement: | -6.0mm~+6.0mm(0.05mm/step) |
Dimension of figure: | 510(L)×490(W)×400(H)mm |
Weight: | 49KG |
Power: | 220V±10%50Hz |
Power: | 500W |
