Product Code: LM-800
The LM-800 Auto Lens Meter combines advanced Hartmann principle technology with a large 7-inch LCD screen to deliver fast, accurate, and reliable lens measurement for optical professionals. Whether you run a busy optical retail store, a lens manufacturing lab, or a clinical practice, this device is engineered to streamline your daily workflow.
| Range of Measurement | |||||||
| Sphere | 0~±25m-1 (0.01/0.12/0.25 m-1) | ||||||
| Cylinder | 0~±10m-1 | ||||||
| Addition | 0~±10m-1 | ||||||
| Axis | 0°~180° (1° step) | ||||||
| Prism Base Angle Measurement Range | 0°~360° | ||||||
| Prism | Horizontal 10△, Vertical 15△, 0.01/0.12/0.25 △ step | ||||||
| Measurement Mode | |||||||
| Cylinder | +,+ / -,- | ||||||
| Prism | X-Y, P-B | ||||||
| Speed of Measurement | 0.2 second | ||||||
| Diameter of Measurable Lens | 18~110 mm | ||||||
| Other Parameters | |||||||
| Dimension | 225* 212* 473mm | ||||||
| Weight | ~5.1KG | ||||||
| Power Supply | AC100~240V 50~60HZ 25VA | ||||||
