LS-8 Galilean system,zeiss type slit lamp
Price
$
Login
Item#
LS-8
已选清单
0种
0件
Description
| Specifications： | LS-8 | LS-9 | |||||
| Type: | Galilean system,Zeiss type | Galilean system,Haag-streit type | |||||
| Magnification changer | Rotationg drum change | ||||||
| Eyepiece | 12.5X | ||||||
| Magnification | 6X,10X,16X,25X,40X | ||||||
| Field of view | 6x(Ф33),10x(Ф22),16x(Ф14),25x(Ф8.6),40x(Ф5.6)mm | ||||||
| Diopter adjustment range : | ±8D | ||||||
| Slit width | continuously from 0~14mm | ||||||
| Slit length: | continuously from 1~14mm | ||||||
| Slit aperture | Ф0.2,Ф1,Ф2,Ф5,Ф10,Ф14(mm) | ||||||
| Filters: | Heat absorption,grey, Red-free, Cobalt Blue | ||||||
| Light Resource | Warm LED | ||||||
