LS-5 Universal Digital Slit Lamp

Price

$ Login

Desc

Price incl

Item#

LS-5

已选清单

0种 0件

Send Inquiry

Add To Cart

Description

CE,FDA,ISO

Comparison of LS series Slit Lamps
Model#	Style	Total Magnifi cation	Magnif Changer	Eyepiece Magnif	Filter	Slit Inclination	Slit Width	Slit Height	Slit Angle	Light spot
LS-1A	Converging Stereoscope	10X		10X	Neutral Density, Red-free, Cobalt Blue	--	0.1mm, 0.2mm, 0.8mm, Ф1mm, Ф5mm, Ф12mm Circle	8mm, 12mm,	±60	--
LS-1B	Converging Stereoscope	10X,16X	1 steps	10X,16X	Neutral Density, Red-free, Cobalt Blue	--	0.1mm, 0.2mm, 0.8mm, Ф1mm, Ф5mm, Ф12mm Circle	8mm, 12mm,	±60	--
LS-3	Galilean Stereoscope (LED)	10X, 16X, 25X	3 steps by drum	12.5 X	Heat Absorption, Grey, Red-free, Cobalt Blue	0°,5°, 10°,20°	0~14mm	1~14mm	0~180°	φ14mm ,φ10mm, φ5mm, φ3mm, φ1mm, φ0.2mm, 1~14mm
LS-4	Galilean Stereoscope (LED)	6x,10×,16×, 25x,40x	5 steps by drum	12.5 X	Heat Absorption, Grey, Red-free, Cobalt Blue	0°,5°, 10°,20°	0~14mm	1~14mm	0~180°	φ14mm, φ10mm, φ5mm, φ3mm, φ1mm, φ0.2mm, 1~14mm
LS-5	Galilean Stereoscope (LED light source, Co-axial background illumination)	6x,10×,16×, 25x,40x	5 Steps by drum	12.5x	Heat Absorption, Grey, Red-free, Cobalt Blue	0°,5°, 10°,20°	0~14mm	1~14mm	0~180°	φ14mm, φ10mm, φ5mm, φ3mm, φ1mm, φ0.2mm,
LS-7	Converging Stereoscope (With Basic, Standard, Expert Digital, 3 level to choose)	6.3X,10X, 16X, 25X,40X	5 Steps by drum	12.5x	Heat Absorption, Grey, Red-free, Cobalt Blue	0°,5°, 10°,20°	0~14mm	1~14mm	0~180°	φ14mm, φ10mm, φ5mm, φ3mm, φ1mm, φ0.2mm,
LS-7DS	Converging Stereoscope (Digital Slit Lamp)	6.3X,10X, 16X, 25X,40X	5 Steps by drum	12.5x	Heat Absorption, Grey, Red-free, Cobalt Blue	0°,5°, 10°,20°	0~14mm	1~14mm	0~180°	φ9mm, φ8mm, φ5mm, φ3mm, φ2mm, φ1mm, φ0.2mm

Features:

• Integrated Auto-Adapt System

• Professional Image

• Packing&Manage Software

• Original light splliter,better photography

• Background light of polarless dimming on base and handle shooting;

• Software control box, it's adaptive software, easy to install.

Specifications:
Optical system
Microscope type:	Galilean system,Parallet type
Magnification changer:	Rotating drum change
Total magnification:	6X,10X, 16X, 25X,40X
Ocular magnification:	12.5 X
Field of view:	6x(Φ33mm),10X(Φ22mm),16x(Φ14mm),25x(Φ8.5mm),40x(Φ5.5mm)
Inter pupillary distance:	52mm～82mm
Diopter adjustment:	-7D~+7D
Slit illumination
Illumination Type	Haag streit type
Slit image width:	0～14mm continuously adjustable
Slit image length:	1～14mm continuously adjustable
Slit image radial range:	0～180° continuously adjustable
Filters:	Heat aborption, grey, redfree(green), cobalt blue
Slit aperture size	Φ0.2,Φ1,Φ3,Φ5,Φ10,Φ14(mm)
Illumination tilting	5°,10°,15°,20°
Max Illumination Intensity	600000 Lux
Light source:	Imported LED
Backgound illumination	Co-axial
Aperture	None
Digital focus mode	Eyepiece reticle
Software	Adaptive parameters
Power Supply
Input voltage:	100-240V 48-62HZ
Input power:	70VA
Dimensions and weight
Dimensions	740640450mm
Net weight:	21kg
Gross weight:	24kg
